42.5°FA+8°isolator FA-MT jumper series is widely used in the internal connection of high-speed optical transceiver. The 42.5° FA is used as the direct coupling of RX fiber to the PD array and the 8° FA is used as the direct coupling of TX fiber to the LD array. The 8° FA with isolators is beneficial for increasing the isolation. The MT ferrule is used as an optical interface inside high-speed transceiver. The MT core can bedirectly connected through the guide Pin following MT standards.

• Accurate fiber core spacing
• Excellent environmental stability and reliability
• Low insertion loss
• Accurate polishing angle
• Customization acceptable
• ROHS and REACH compliant

• High speed optical transceiver
