Pluggable Lens Attached Fiber Array
Introduction
Pluggable lens attached fiber array has a high-precision lens array aligned and bonded automatically to the fiber array. With this lens array, the customer can focus light to the other optical component in high-speed data communication device. The output beam pointing angle is less than 0.15 degrees. With the high precision Pin and Pin hole, the fiber array is pluggable and achieve passive alignment.
Features
- Output beam pointing angle less than 0.15 degrees
- High stable performance
- Accurate fiber core pitch
- Up to 24ch fiber
- Excellent environmental stability and reliability
- Low insertion loss
- Customization acceptable
- ROHS and REACH compliant
Application
- Lidar
- High speed optical transceiver
- Multi-channel integrated micro-optics device
- Coherent communication
