42.5° Fiber protrudedarray
Introduction
The 42.5°fiber protruded array is made of high-precision V-groove, special epoxy and other raw materials.The optical fiber is protruded from the V-groove with excellent protrusion uniformity. The unique polishing process ensures surface flatness of fiber endface and polishing angle accuracy to achieve total reflection.
Features
- Accurate fiber core pitch
- Up to 12 channels
- Excellentenvironmental stability and reliability
- Low insertion loss
- Accurate polishing angle
- Customization acceptable
- ROHS and REACH com
Application
- Multi-channel integrated micro-opticsdevice
- High speed optical transceiver
